Very High Frequency Marine Transceiver(VHF)
The marine Class A VHF has a good intercom communication effect, built-in DSC function, has good waterproof performance, and the waterproof level reaches lP56. Our VHF9000 radio already comply with MSC.1/Circ.1460/Rev.3 (4 digit channel list)
The VHF marine transceiver is compliant with the regulations of ITU-R M.493-15, IMO MSC.302 (87)IMO MSC.1/CirC.1460, IMO MSC.511(105), IEC 60945,IEC 61097-8:1998,1EC 61097-3:2017,IEC 61097-7:2018IEC 61097-7:2018,1EC 61097-8:2011,EC 61097-8:2011,EC 61097-8:2011,1EC 61097-8:2011IEC 61097-8:2011,EC61097-3:2017,EC61097-7:2018,EC 62923-1:2018,1EC 62923-2:2018.
Specifications
General
| Frequency Range | TX:156.000～162.000MHz RX:156.000～163.450MHz |
| Mode | FM(16K0G3E),DSC(16K0G2B) |
| Power Supply | DC 12V(-10%/+30%) |
| Antenna Impedance | 50Ω |
| Size(L×W×H) | W(220)×H(98.5)×(D)161.5mm |
| Unit Weight | 1400g(±2%) |
| DSC Class | Class A |
| DSC ReceiveSensitivity | ≤ -111dBm(1%BER) |
| Waterproof | IP56 |
| Channel Spacing | 25kHz |
Transmitter
| Output Power | 25W/1W |
| Maximum Frequency Offset | ±5KHz |
| Adjacent Channel Power | <-70dB |
| Signal To Noise Ratio | >40dB |
| Current Consumption | High Power<5.5A Low Power≤1.5A |
| Input lmpedance | 2KΩ(Microphone) |
Receiver
| Receive Sensitivity | ≤ -120dBm (12dB SINAD) |
| Spurious Response | ≥70dB |
| Adjacent Channel Selectivity | ≥70dB |
| Intermodulation Immunity | ≥68dB |
| Audio Output Power | ≥4.5W(10%) |
| Gps Data Format | NMEA0183-2.0 |
| Output lmpedance | 4Ω(Speaker) |
